Sunset Solar Panels SM 30 L

Small Module (Laminated) - SM 30 L

Solar generator SM 30 L has been developed as a laminated module (without frame) especially for use in small and middle, private and industrial appliances (e.g. battery top-up charging, independent power supply for mobile weather stations, lighting for weekend chalet, independent power supply for pumping systems etc.). The used monocrystalline silicon cells achieve a peak power of 30 Wp. The front cover consists of high quality plexiglas used as solar glazing, and an aluminium and plastic composite used for the back plate.

The high quality materials allow the module to be bent slightly to fit curved surfaces. The electrical connection for this module utilises a sealed connection box with a 0.5m cable.

  • Article No. 10034

  • Rated power Pmax [Wp] 30

  • Rated current Impp [A] 1,74

  • Rated voltage Umpp [V] 17,3

  • Short circuit current Isc [A] 1,93

  • Open circuit voltage Uoc [V] 20,8

  • Length [mm] 681

  • Width [mm] 336

  • Height [mm] 8

  • Height connection box [mm] 11

  • Weight 1.28kg

Technical Specifications:

Please note technical specifications are subject to alternations without prior notice.

Guarantee: 2 year warranty covering failure and a 10 year warranty against the power produced by the solar panel reducing, from that produced when the panels were new.
