Sunset Solar Panels AS 90 27 HPC

The solar generator AS 90 27 HPC consists of high powered monocrystalline 5 inch cells (HPC), made of SUNsilicon ®. The cells distinguish themselves by particularly high electricity output, even on cloudy days. The tried and tested module design protects the solar cells against moisture, gives UV stability, and allows for thermal expansion. The front covering is made of top quality tempered solar glazing. The solar glazing and the solar cell laminate are joined together into a unit and mounted in a torsion resistant frame, made of anodized aluminium.

The solar modules of the AS HPC family are well protected from mechanical and climatic influences. The connection is housed in a weatherproof wiring box at the back in which also the bypass diodes are mounted. Due to their high efficiency the solar generators AS HPC are mainly used in solar arrangements like tracking systems or roof top installations.

  • Nominal power (±5%) Pmax [Wp] 90

  • Rated current IMPP [A] 5.70

  • Rated voltage VMPP [V] 15.8

  • Short circuit current ISC [A] 5.95

  • Open circuit voltage VOC [V] 18.4

    Peak power under test conditions (ST C: 1000 W/m2, 25°C, spectrum AM 1,5)

  • Protection class II

  • System voltage VSYS [V] 1000

  • Reverse current IR [A] 15

  • Temperature coefficient ISC α [%/K] + 0.06

  • Temperature coefficient VOC β [%/K] - 0.28

Technical Specifications:

Please note technical specifications are subject to alternations without prior notice.

Guarantee: 2 year warranty covering failure and a 10 year warranty against the power produced by the solar panel reducing, from that produced when the panels were new.

Characteristics For System Design:

Mechanical Characteristics:

  • Front covering 3.2 mm solar glass

  • Back covering multi layer foil

  • Type of cell mono crystallin

  • Dimensions 1040 x 528 x 35 mm

  • Protection class junction box IP 65

  • Cable connection Multi Contact

  • MC3 or compatible

  • Weight 6.7 kg

At a glance:

  • 27 high-powered monocrystalline silicon solar cells (HPC) made from SUNsilicon ® with an efficiency up to 20%

  • High current and higher power output compared to other modules

  • Electrical contacts are on the back of the cell leaving the entire front surface available to absorb and convert the sun rays

  • Smooth and dark surface which is free of metal gridlines gives a very stylish and modern appearance

  • Manufactured under German quality standards

  • Also suitable for SUNpower Roof integration system and SUNpremium ® field mounting system
